Sheet Metal Fabrication · OEM & ODM · Prototyping
One Drawing In, A Finished Part Out
Laser cutting, CNC bending, welding and surface finishing run inside our own factory — so your drawing moves from DFM review to a certified, shipped part without a single sub-contractor.
6000 W
Fiber laser cutting, 12 machines
±0.1 mm
Cut and form tolerance, in contract
48 h
Quotation, drawing in to price out
7 days
First article for prototype orders
Six process stages, all under one roof
Every stage runs on our own shop floor. No subcontracting between laser, bend, weld and finish — which means one tolerance standard, one schedule and one point of accountability from blank to shipped part.
01
Laser Cutting
Twelve 6000 W fiber laser cutters profile mild steel, stainless, aluminium, copper and galvanised sheet — up to 25 mm on carbon steel and 16 mm on stainless, holding ±0.1 mm without an edge break.
- Equipment 6000W fiber laser x12
- Thickness 0.5 - 25 mm
- Tolerance +/-0.1 mm
02
CNC Bending
Eighteen 200 T servo press brakes in 3.2 m, 4 m and 6 m formats form complex parts, with spring-back compensated per part rather than per operator.
- Equipment 200T servo press brake x18
- Max length 4000 mm
- Tolerance +/-0.5 deg
03
Precision Welding
Robotic MIG and TIG, spot and hand welding in carbon steel, stainless and aluminium. Weldments are fixtured, tacked and welded to a written procedure, then checked for distortion.
- Process MIG / TIG / spot
- Material Carbon steel / aluminium / stainless
- Strength 1.5x load test
04
Surface Finishing
Our own powder line, plus qualified anodising, zinc plating, brushing and blasting partners. RAL and Pantone colour matching on every batch.
- Process Powder / anodise / plate
- Film thickness 60 - 120 um
- Colour Delta E <= 1.5
05
Riveting and Assembly
PEM nuts, studs, standoffs and blind rivets pressed to drawing torque, then mechanically assembled, labelled and kitted so the part arrives ready to build.
- Operation Rivet / blind rivet / assembly
- Rivet force 3 - 12 kN
- First-pass yield >= 99.6%
06
Inspection & Delivery
Two CMMs, three optical projectors, salt-spray and hardness testing. Every shipment leaves with an inspection report and an EN 10204 3.1 material certificate.
- Equipment CMM / optical projector / caliper
- Sampling AQL 0.65
- Lead time 7 days proto / 15 days production
The numbers we will sign
Machine limits, achievable tolerances and the design rules our engineers apply to your drawing. If a dimension falls outside these limits, we tell you before you cut a tool.
Maximum blank size
2500 × 1250 mm
Sheet thickness
0.5 – 25 mm carbon · 0.5 – 16 mm stainless
Cutting tolerance
±0.1 mm general · ±0.05 mm hardware holes
Bending capacity
200 T · 3.2 / 4 / 6 m press brakes
Bend angle
±0.5° · minimum inside radius 0.5 × t
Lead time & certificates
7 days prototype · EN 10204 3.1 mill certs
Design for manufacturability
Minimum bend radius 1 × t · hole to edge 2 × t · hole to hole 6 × t
Relief cut 1 × t wide, 1.5 × t deep · minimum flange 4 × t
Weldable thickness from 0.8 mm · countersink 82° or 100° · corner fillet 0.5 × t
How We Work
Six trackable steps, from enquiry to after-sales
01
Requirement
Send a drawing, a STEP file or a sample. We confirm the material, thickness, finish and the tolerance the application actually needs.
02
Drawing Review
Our engineers run a DFM review — bend radius, hole spacing, tool access, tolerances — and the cheapest way to hold them.
03
Quote & Prototype
Quotation inside 48 hours. On approval the first article is cut, bent, finished and measured before series production starts.
04
Production
Scheduled onto the line under a job number per batch, so every part carries the same revision, the same material and the same recipe.
05
Inspection & Shipment
First-article and in-process sampling against the drawing, then export packing, carton marks and courier handover.
06
After-sales
Quality questions answered within a working day by the same engineer who reviewed the drawing.
Engagement Models
Three ways to work with us
OEM Manufacturing
We produce to your drawings and your revision, on our own machines, under your quality agreement. MOQ from 1 piece, so prototypes and production run through the same door. Lead time 15 – 25 days.
- Minimum order From 1 piece
- Lead time 7 - 15 days
ODM Co-development
We join at structural design stage — material, bend sequence, tolerances, coating, assembly — and hand back a drawing package your team can release to anyone. MOQ from 50 pieces. Lead time 25 – 30 days.
- Minimum order From 50 pieces
- Lead time 25 - 40 days
Rapid Prototyping
Quote in 48 hours, first article in 7 days. One-off and small-batch parts, measured and documented, to de-risk the design before tooling. Lead time 7 – 10 days.
- Minimum order From 1 piece
- Lead time 7 days
Quality Control
Tolerances go in the contract, not the conversation
Critical dimensions are confirmed on the drawing before the first cut, then verified on the bench and on the CMM. Nothing is shipped against a verbal agreement.
| 标称尺寸范围 (mm) | 线性公差 (mm) |
|---|---|
| 0.5 – 3 | ±0.10 |
| 3 – 6 | ±0.10 |
| 6 – 30 | ±0.20 |
| 30 – 120 | ±0.30 |
| 120 – 400 | ±0.50 |
| 400 – 1000 | ±0.80 |
| 1000 – 2000 | ±1.20 |
| 2000 – 4000 | ±2.00 |
Industries
Six sectors, one tolerance standard
From tier-one automotive to medical devices, the same inspection regime and the same paperwork run through every sector we serve.
Automotive Components
Body structures, battery trays, seat frames, EV enclosures.
Telecom & 5G Equipment
Cabinets, antenna brackets, heat-sink frames, outdoor enclosures.
Medical Instruments
Device housings, bed frames, instrument carts, clean-room cabinets.
New Energy
Energy storage cabinets, PV mounting, inverters, cooling skids.
Industrial Automation
Control cabinets, robot bases, conveyor frames, guarding.
Rail Transit
Platform screen doors, interior fittings, equipment brackets.
Materials
The grades we run every week
Material is stocked in-house, so the grade on your drawing is the grade on your certificate.
Carbon Steel
- SPCC (cold rolled)
- Q235 / S235JR
- Q355 / SAPH440
- Pickled & oiled HR
- Thickness 0.5 - 25 mm
- Use frames / brackets / enclosures
Stainless Steel
- SUS 301
- SUS 304 / 304L
- SUS 316L
- SUS 430
- Thickness 0.5 - 16 mm
- Use food / medical / outdoor
Aluminium
- 1050 / 1060
- 5052 H32
- 5754 / 6061
- 6063 / 7075
- Thickness 0.5 - 20 mm
- Use panels / heatsinks / carts
Galvanised & Al-Zn
- DX51D + Z275
- Galvanneal
- Al-Zn coated steel
- Pre-painted options
- Thickness 0.5 - 6 mm
- Use telecom / energy enclosures
Brass, copper, spring steel and titanium are cut to order with a 5 – 8 day material lead time. Tell us the grade and we will confirm the certificate that ships with it.
Surface Finishing
Finish to your written standard
Powder runs on our own line; every other finish is applied by a qualified partner and inspected here before packing.
Powder Coating
Our own line, in-house. Flat, matte, fine texture, high gloss. RAL and Pantone matched, cured at 200 °C.
- Line In-house powder booth
- Film 60 - 120 um
- Colour match Delta E <= 1.5
Anodising
Type II and hardcoat Type III on aluminium, to MIL-A-8625. Clear, black or colour.
- Route Qualified partner
- Type Type II / hard
- Colours Clear / black / natural
Zinc Plating
Trivalent, hexavalent-free passivate. RoHS compliant, clear, yellow or black.
- Route Qualified partner
- Passivate Trivalent
- Salt spray 24 - 240 h
Brushed & Bead Blast
Hairline brushing, matte bead blast and fine satin for enclosures and panels.
- Finish Hairline / bead blast
- Roughness Ra 0.8 - 1.6
- Media Glass bead 80 - 120
Silk-Screen & Engraving
Logos, scale marks, part numbers and data-matrix codes, laser or screen printed.
- Method Screen / laser
- Content Logo / scale / S/N
- Colour Per Pantone
E-Coat & Passivation
Electrophoretic coating on complex assemblies, plus nitric and citric passivation to ASTM A967.
- Route Qualified partner
- Coverage Full immersion
- Record Batch cert
Why Us
Six reasons buyers keep the same supplier
The claims below are the same ones written into your purchase order and the report that ships with the parts.
01
All six stages in-house
No subcontracting between laser, bend, weld and finish. One schedule, one tolerance standard, one team answerable for the part.
02
Quotation in 48 hours
Engineers review drawings the day they arrive, with manufacturability comments and real pricing, not a form response.
03
First article in 7 days
Prototypes are sampled on the same machines as production, so a good prototype means a good production run.
04
Tolerances in the contract
Laser ±0.1 mm, bend ±0.5°, hole ±0.05 mm — written into the purchase order and verified on the report.
05
From one piece
No minimum order for prototypes, and no minimum for repeat batches below 500 pieces.
06
After-sales within 24 hours
Quality questions are answered within a working day by the engineer who reviewed the drawing.
Frequently Asked Questions
Short answers here; the full FAQ is on the contact page.
There is no minimum. We manufacture to your drawings from a single piece. For co-development projects where our engineers join at the structural design stage, the practical starting point is 50 pieces.
Within 48 hours of receiving your drawings or samples. Send DXF, DWG, STEP or PDF along with your material and surface finishing requirements, and we will come back with pricing and any manufacturability questions.
First article prototypes take 7 days. Production orders run 7 to 15 days depending on batch size and complexity. Co-development projects that include structural design input typically run 25 to 40 days.
All six stages: laser cutting, CNC bending, precision welding, surface finishing, riveting and assembly, and inspection. Nothing is subcontracted between steps, so lead time stays predictable and tolerance stays stable.
Carbon steel, stainless steel and aluminium across cutting, bending and welding. Plate thickness runs from 0.5mm to 25mm on our 6000W fiber laser equipment.
Laser cutting to plus or minus 0.1mm and bending angles to plus or minus 0.5 degrees. Hole position to plus or minus 0.05mm. Critical dimensions are confirmed on the first article at 100 percent, then sampled to AQL 0.65 during production.
Yes. Every shipment includes an inspection report and material certificates. We use CMM, optical projectors and calipers across three sampling levels, and inspection records are kept for two years and available on request.
Powder coating, anodising and zinc plating. Film thickness of 60 to 120 micrometres, with colour difference held to Delta E of 1.5 or better. We run our own powder line plus a qualified subcontract route for finishing.
We operate under an ISO 9001 certified quality management system, covering both manufacturing processes and inspection procedures.
Yes. Our engineering team runs a DFM review on your drawings and flags manufacturability issues along with cost-down options, before any tooling is committed.
Send your drawings or samples through the contact page, or message us on WhatsApp at +86 159 9293 5461. Include material, batch size and your target date, and we will respond the same day.
Send us your drawing, quote within 48 hours
DXF, DWG, STEP and PDF accepted. Tell us the material, the finish and the tolerance — we come back with price, lead time and any manufacturability notes.
